Reyee RG-ES205GC-P
RUIJIE REYEE RG-ES205GC-P 5 PORT 10/100/1000 4 PORT POE+ 54W RUJIE CLOUD YONETILEBILIR DESKTOP SWITCH
VLAN Configuration on Mobile Phones,Visualized Configuration Experience
Breaking new ground with easy operationexperience on mobile phones
Failure Alarm and Fault Positioning
Quick Response — Excellent Troubleshooting Assistant
Remote Single-port Restart
Port restart is a better solution than equipment restart. Single-port restart is a better solution than restartingall the ports. Remote single-port restart is even betterthan on-sitesingle-port restart.
Auto Equipment Discovery
|
Model Specifications |
|
|
Model Specifications |
RG-ES205GC-P |
|
Hardware specifications |
|
|
Ports |
4 10/100/1000 Base-T ports (PoE/PoE+), 1 10/100/1000 Base-T port |
|
Maximum output power per PoE port |
30W |
|
Maximum PoE output power per switch |
54W |
|
Switching capacity |
10Gbps |
|
Packet forwarding rate |
7.44Mpps |
|
Surge protection |
Common mode: 4KV |
|
Electrostatic discharge |
Air discharge: 6KV Contact discharge: 4KV |
|
Power consumption |
≤60W |
|
Power supply |
External power adapter |
|
Dimensions (W x D x H) |
148*78*26mm |
|
MTBF |
>200K |
|
Operating environment |
|
|
Operating temperature |
0 to 40°C |
|
Storage temperature |
-40~70ºC |
|
Operating humidity |
10% to 90% RH |
|
Storage humidity |
5% to 95% RH |
|
Software features |
|
|
MAC capacity |
2K |
|
Static MAC address |
16 |
|
VLAN |
Support 802.1Q VLAN |
|
Port management |
Support port status display, port traffic statistics, PoE port output power status, port duplex / negotiation rate configuration, flow control configuration, PoE output on/off |
|
Security |
Support broadcast storm suppression, port speed limit, port isolation |
|
L2 features |
Support port mirroring, loop protection, cable detection |
|
Management |
Support management and configuration through web management interface, Ruijie Cloud platform and Ruijie Cloud app |
